GM2 Series General Purpose Micro Drives

Sensorless Vector Control Technology
Built-in EMC Filter
DIN Rail Mounting up to 7.5HP
ignoreGeneration#Zoomable Image
ignoreGeneration#Zoomable Image
Price Price Available on Request
Fast Delivery
Technical Support
EN618000-3 & UL Open Compliant

Trusted by Hundreds of Companies Globally

Technical Specifications at a Glance

Comprehensive technical details for the GM2 Series General Purpose Micro Drives to help you make informed decisions.

PARAMETER
SPECIFICATION
Dual Rating
Normal and Heavy Duty: 240V: 1HP~15HP (ND), 0.5HP~10HP (HD); 480V: 1HP~15HP (ND), 0.5HP~10 HP (HD)
Display
4 digit, 7 Segment with 4 LED Indicators
Protected Chassis
UL Open (IP20)
EMC Filter
480V only
Internal Brake IGBT
Yes
Single Phase Input
Derating required
Control Modes
V/Hz, Sensorless Vector, Slip Compensation
Features
Auto Tuning, Torque Limits, PID Control, Regen Avoidance, Kinetic Energy Buffering (KEB), Ride Through
Communication
Modbus-RTU standard, optional Ethernet/IP, Modbus-TCP
Country of Origin
🇺🇸 USA

Engineered to Perform

Advanced features and robust design make the GM2 Series the ideal choice for demanding industrial applications.

Sensorless Vector Control

High torque at low speed operation with precise motor control for demanding applications requiring superior performance and reliability.

Built-in EMC Filter

Embedded C3 EM filter ensures EN618000-3 standards compliance, reducing electrical interference and maintaining clean power quality in industrial environments.

DIN Rail Mounting

Compact design allows DIN rail mounting up to 7.5HP, perfect for space-constrained panel installations and OEM applications.

KEB Operation

Kinetic Energy Buffering maintains DC link voltage during power loss, ensuring continuous operation and protecting your processes from interruptions.

Enhanced Thermal Design

Advanced thermal resistance materials and airflow construction minimize exposure to contaminants while ensuring reliable operation in harsh environments.

Dual Rated Operation

Flexible Normal and Heavy Duty ratings provide optimal performance across a wide range of applications and operating conditions.

Frequently Asked Questions

What is the maximum horsepower rating for DIN rail mounting?
The GM2 Series supports DIN rail mounting up to 7.5HP, making it perfect for compact panel installations and OEM applications where space is limited.
Does the drive include built-in communication capabilities?
Yes, the GM2 Series includes Modbus-RTU standard with an RJ45 port. Optional Ethernet/IP and Modbus-TCP communication modules are also available for advanced networking requirements.
What is KEB operation and how does it benefit my application?
KEB (Kinetic Energy Buffering) maintains DC link voltage during power loss, allowing the drive to continue operating through brief power interruptions and protecting your process from costly shutdowns.
Can I use single-phase input with this drive?
Yes, single-phase input is supported but derating is required. Contact our technical team for specific derating calculations based on your application requirements.
What software is available for commissioning and monitoring?
WinDRIVE PC-based software is available for commissioning and monitoring, providing comprehensive tools for setup, diagnostics, and real-time parameter monitoring of your GM2 Series drives.

Versatile Applications Across Multiple Industries

The GM2 Series drives are designed to excel in demanding industrial environments, providing reliable motor control solutions for diverse applications.

Packaging Materials

Distributor Stocking

Perfect for distributor stocking programs requiring reliable, cost-effective variable frequency drives with proven performance and technical support.

Fishnet Manufacturing

OEM Panel Builders

Compact design ideal for OEM panel builders with space constraints, offering DIN rail mounting and integrated control features.

PPMF Tapes & Twines

General Purpose Applications

Versatile solution for general purpose applications requiring variable frequency drive control with sensorless vector performance and reliability.

What Our Clients Say

Discover how the GM2 Series has helped companies achieve their motor control objectives with reliable performance and outstanding support.

Outstanding performance in compact design

The GM2 Series drives have been perfect for our panel builds. The DIN rail mounting saves space and the built-in EMC filter eliminates interference issues we had with other drives.

MJ

Mike Johnson

Senior Engineer, Industrial Controls Inc.

Reliable operation with excellent support

ValuAdd's technical expertise combined with Benshaw's GM2 drives has been a winning combination. The KEB feature has saved us from multiple power interruptions.

SR

Sarah Rodriguez

Plant Manager, Precision Manufacturing

Perfect for our distributor program

The GM2 Series is an ideal stocking item. Customers appreciate the dual rating flexibility and the built-in communication capabilities. Sales have been consistently strong.

DL

David Lee

Sales Manager, Industrial Supply Co.

Exceptional technical features

The sensorless vector control and flying start capability have been game changers for our conveyor applications. Installation was straightforward with excellent documentation.

TC

Tom Chen

Automation Engineer, Material Handling Systems

Cost-effective solution with premium features

We've standardized on the GM2 Series for our machine builds. The built-in potentiometer and diagnostic features reduce our commissioning time significantly.

LW

Lisa Williams

Design Engineer, Custom Machine Builder

Robust design for harsh environments

The enhanced thermal resistance design has performed flawlessly in our high-temperature manufacturing environment. The fan life-cycle diagnosis is a valuable maintenance feature.

RG

Robert Garcia

Maintenance Supervisor, Steel Processing
